SG110-16HP-EU - Cisco SMB SG110-16HP-EU SG110-16HP 16-Port PoE Gigabit Switch

Cisco SG110-16HP, Small Business. Switch layer: L2, Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Copper ethernet cabling technology: 1000BASE-T, 100BASE-TX, 10BASE-T. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x. Switching capacity: 32 Gbit/s, Throughput: 23.8 Mpps. Colour of product: Black, Certification: UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B

Management features
Switch layer* L2
Switch type* - Unmanaged
Quality of Service (QoS) support - Yes

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity* - 16
Basic switching RJ-45 Ethernet ports type* - Gigabit Ethernet (10/100/1000)
Copper ethernet cabling technology 1000BASE-T, 100BASE-TX, 10BASE-T
Gigabit Ethernet (copper) ports quantity - 16

Networking
Networking standards* - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
Full duplex - Yes
Head-of-line (HOL) blocking - Yes
Flow control support - Yes
Auto MDI/MDI-X - Yes

Data transmission
Switching capacity* 32 Gbit/s
Throughput 23,8 Mpps
Number of queues 4
Jumbo frames support - Yes

Design
LED indicators - Yes
Certification - UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A, FCC Class B

Performance
Flash memory 128 MB
Internal memory 128 MB

Power
AC input voltage 110-240 V
AC input frequency 50/60 Hz

Power over Ethernet (PoE)
Power over Ethernet (PoE) support * - Yes
Power over Ethernet (PoE) ports quantity - 8

Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 10 - 90 %
Storage relative humidity (H-H) 5 - 90 %

Weight & dimensions
Width 27,94 cm
Depth 17 cm
Height 4,45 cm
Weight 1,4 kg

Packaging data - Quick start guide
